Generating quantity take-off report for Reinforcement The quantity table should first be inserted into the respective drawings by checking the “Insert Quantity Table” when generating drawings from the detail drawing manager. To generate the reinforcement quantity take-off report: Select the quantity take off table for the respective drawings. If you wish to generate multiple tables […]

When modelling a truss in ProtaStructure, it must be supported by a column, wall or another beam. Hence, the supporting member must be modelled for the truss to sit on.  If you want to assign a special support, such as a roller support, it must be always be applied to the bottom of a column, […]

Many structures will undergo a natural sway under purely vertical (gravity) loads. These sways can sometimes introduce significant changes to the expected moment diagrams in beams. The axial force & moment of the columns and walls can also be significantly changed due to sway. In such cases it is important to ensure that checks are made […]

Beams which are created in a single axis will automatically become continuous beam in the beam design.  A simple example model is created as below :                                                            […]

General Column schedule grouping can be performed for columns with same size and reinforcement requirements. This will significantly reduce drafting requirements for large projects with repetitive column detailing.  Follow steps below to perform grouping in column schedule:- In Draw Details – Column Schedule, go to Options Tab and check option Group Similar Columns.  Click Draw  and pick an insertion point […]

General Text height of dimensions (e.g. beam dimension, column dimension, etc) and labels (beam label, column label, etc) can be adjusted in ProtaDetails. Method 1 Adjusting Text Height in the Layers. Go to "Settings" > "Layers and Texts Style" Adjust the "Text Height (mm)" respectively based on the Description. Click "OK" Take note that "Text Height (mm)" has a maximum cap […]

Curved Reinforced Concrete (RC) wall is currently beyond the scope of ProtaStructure. However, as a work around you can approximately model it as a series of segmented straight RC walls. Model the axes according to the angle of your curved wallIn this example, the shape of the curved wall is as shown below.  Now model […]

This article explains: the wall braced direction mentioned in Settings Center will be following the direction of the global axis system the wall braced direction mentioned in Section Design will be following the direction of the member local axis system Braced Direction In Settings Center In Settings Center > Lateral Drift & Bracing, the braced direction […]

Introduction Traditionally, continuous beam lines are analyzed and designed in isolation. The modelling of the support conditions in such cases is often unsophisticated or simplified. For example, in the analysis of secondary beams supported by primary beams, the traditional method is to perform two analyses independently and separately: Firstly, the secondary beam frame line is […]
